CKD cylinder Selex SCA2 series Intermediate trunnion (SCA2-TC-80B-200-T2H-D)

CKD cylinder Selex SCA2 series Intermediate trunnion (SCA2-TC-80B-200-T2H-D)

6,959.13 ฿
6,959.13 ฿
Sale Sold out

CKD

รายละเอียด CKD cylinder Selex SCA2 series Intermediate trunnion (SCA2-TC-80B-200-T2H-D)

Technical data :

Light weight / High corrosion resistance

    The main aluminum parts including both end caps, piston and pipe allow
    The piston body is lighter. It has higher corrosion resistance and impact resistance.

Mounting bracket/switch type, easy to change

    Compatible adapters for different mounting brackets allow for easy replacement and efficient inventory management.
    The cylinder is equipped with a magnet as standard. It allows switching types by simply installing the desired sensor switch.

Specifications

Inner diameter of pipe (Φmm) 80
Stroke (mm) 200
How to stimulate double acting type
How to install Center trunnion type
Cylinder switch detection Magnet(cylinder switch detection) available
pad There are air cushions on both sides.
Connection diameter RC1/2
liquid used Compressed air
Maximum working pressure (MPa) 1
Minimum working pressure (MPa) 0.05
Pressure resistance (MPa) 1.6
Ambient temperature (℃) -10 to 60 (does not freeze)
Used piston speed (mm/sec) 50～1000
Effective length (mm) 20.6
Allowable absorption energy (J) 27.9
refueling Not required (use Class 1 ISO VG32 turbine oil when refueling)
Mass (kg) 5.8
Switch (Cylinder) 2-wire contact type, 1-color display type
