CKD cylinder Selex SCA2 series Intermediate trunnion (SCA2-TC-80B-150-T0H3-D)
CKD cylinder Selex SCA2 series Intermediate trunnion (SCA2-TC-80B-150-T0H3-D)
Regular price
6,422.34 ฿
Regular price
Sale price
6,422.34 ฿
Unit price
/
per
CKD
รายละเอียด CKD cylinder Selex SCA2 series Intermediate trunnion (SCA2-TC-80B-150-T0H3-D)
Light weight / High corrosion resistance
The main aluminum parts including both end caps, piston and pipe allow
The piston body is lighter. It has higher corrosion resistance and impact resistance.
Mounting bracket/switch type, easy to change
Compatible adapters for different mounting brackets allow for easy replacement and efficient inventory management.
The cylinder is equipped with a magnet as standard. It allows switching types by simply installing the desired sensor switch.
Specifications
Inner diameter of pipe (Φmm) | 80 |
Stroke (mm) | 150 |
How to stimulate | double acting type |
How to install | Center trunnion type |
Cylinder switch detection | Magnet(cylinder switch detection) available |
pad | There are air cushions on both sides. |
Connection diameter | RC1/2 |
liquid used | Compressed air |
Maximum working pressure (MPa) | 1 |
Minimum working pressure (MPa) | 0.05 |
Pressure resistance (MPa) | 1.6 |
Ambient temperature (℃) | -10 to 60 (does not freeze) |
Used piston speed (mm/sec) | 50~1000 |
Effective length (mm) | 20.6 |
Allowable absorption energy (J) | 27.9 |
refueling | Not required (use Class 1 ISO VG32 turbine oil when refueling) |
Mass (kg) | 5.4 |
Switch | (Cylinder) 2-wire contact type, 1-color display type |
