Murrelektronik Circular Connector Code 7000-13501-9710050

M12 flange mount bulkhead connectors from Murr Elektronik, offered in 4 way and 5 way male and female variants with A coding and TPE wires at 0.5 metres in length. The 4 wire versions (brown, white, black and blue) and the 5 wire versions (brown, white, blue, black, grey) attached wires are multi-stranded 0.34mm², with PP insulation. The connector contacts are rated to a maximum current capacity of 4A and with an overall operating voltage of a maximum of 250 Vac/dc for 4 way connectors and 125 Vac/dc for the 5 way M12 connector versions. These durable M12 bulkhead connectors have an IP67 rating when mated.

Operating voltage 250 Vac/dc max (4 way), 125 Vac/dc (5 way)
Number of wires 4 or 5 x 0.34mm²
Screw thread M12x1mm
IP67 once mated
Operating temperature range -40 to +80 °C

EN60529

MURR Elekronik Sensor - Actuator Cable Assemblies and Connectors

A comprehensive offering of M8 and M12 connector cable assemblies, distribution units, M8 and M12 connectors, fieldbus connector cable assemblies, couplers and tooling from MURR Elektronik.
