Murrelektronik Circular Connector Code 7000-12931-0000000

The Murrelektronik Limited 7000 series 5-contact M12 female self-wireable cable connector has a socket in-line connection. This cable mount connector has a voltage rating of 60VAC/DC and a current rating of up to 4A per contact. This connector features a plug-in mating with a threaded locking mechanism for an easy and secure connection. Its housing is constructed from impact-resistant plastic.
Murrelektronik sensor-Actuator cable assemblies and connectors
A comprehensive offering of M8 and M12 connector cable assemblies, distribution units, M8 and M12 connectors, Fieldbus connector cable assemblies, couplers and tooling from Murrelektronik.
M12 field-wireable cable connectors, screw terminals
M12 field-wireable cable mount connectors from Murrelektronik offered in male and female 5-way straight and right-angled variants. These M12 connectors feature screw terminals allowing in the field construction and repair.

Straight body orientation
Screw termination
Connection cross section ranging between 0.14mm² and 0.75mm²
Easy mating and unmating
Operating temperature ranging between -30°C and 85°C
Outer cable diameter ranges 4mm and 8mm
Unshielded

Machine tools
Manufacturing
Metal cutting
Production lines

EN60529
IP67 rated
