KIMO model CR110 Solar radiation transmitter

Important information because

• Measuring range 0 to 1500 W/m² Measuring range 400-1100 nm
• Unit of measurement W/m²
• Accuracy value: 5% of reading value
• Resolution 1 W/m²
• Can output a signal of 0-10 V or 4-20 mA.
• The machine is made of ABS material, dust and water protection level IP65 (depending on the model).
• There is a numeric display screen.
• The screen is a 10 digit LCD, screen size 50 x 17 mm, number size 10 mm, measurement unit size 5 mm.
• Equipment for wall installation is included in the set.
• Easy, convenient and fast installation

Usage

• Turn on the meter and let it heat up.
• Connect the pressure pipe to the meter.
• Read pressure values ​​on the LCD screen.
• If the pressure value exceeds the safe limit An alarm will sound.

Precautions

• This meter is not waterproof.
• Do not use this meter in areas where other gases are present.
• Check and calibrate this meter regularly.
