Banner Q12 Series Miniature Self-Contained Sensor Code Q2XRBLAF100-Q5

Name: Banner Q12 Series Miniature Self-Contained Sensor Code Q2XRBLAF100-Q5
Brand: BANNER
Price: 3887.53 THB
Availability: InStock

BANNER

3,887.53 ฿

Sale Sold out

Quantity

รายละเอียด Banner Q12 Series Miniature Self-Contained Sensor Code Q2XRBLAF100-Q5

IP Rating	IP67
Sensing Beam	Visible Red LED
Cable Length (m)	0.15
Power	DC
Sensing Mode (General)	Proximity
Sensing Mode (Detailed)	Background Suppression (Fixed)
Housing Style	Rectangular
Primary Housing Material	Thermoplastic
Small Visible Spot	LED
Input Output	Discrete
Max Sensing Distance (mm)	30
Outputs	Bipolar (NPN & PNP)
Power Supply/Supply Voltage	10-30 V dc
Connection	Pigtail QD
Quick Disconnect Type	M8
Min Op. Temp. (°C)	-20
Operation	Light Operate
Max Op. Temp. (°C)	55
Output response time (ms)	0.85 ON/OFF
Special Feature: Intrinsically Safe	No
Special Feature: Remote Teach	No
Special Feature: Water Detection	No
Sensing Beam Wavelength	640
Delay at Power-up (ms)	120
Repeatability (µs)	175
Number of Pins	4
Max Op. Relative Humidity [%]	95% @ 50°C
Lens Material	Polycarbonate
Adjustments	N/A
Indicator	LEDs
Feature: Audible	No	Feature: Quick Disconnect	Yes
