Bearing SKF YAR 210-115-2LPW/SS
Bearing SKF YAR 210-115-2LPW/SS
Regular price
4,741.00 ฿
Regular price
Sale price
4,741.00 ฿
Unit price
/
per
SKF
รายละเอียด Bearing SKF YAR 210-115-2LPW/SS
Dimensions
d |
1.938 in
|
Bore diameter |
---|---|---|
D |
3.543 in
|
Outside diameter |
B |
2.031 in
|
Width of inner ring |
C |
0.866 inches
|
Width of outer ring |
d 1 |
≈ 2.461 in
|
Outside diameter of inner ring |
B 4 |
0.354 inches
|
Distance face to thread center |
r 1,2 |
min. 0.039 in
|
Chamfer dimension of inner ring |
s 1 |
1.283 in
|
Distance from locking device side face to raceway center |
Calculation data
Basic dynamic load rating | C |
6 654 lbf
|
---|---|---|
Basic static load rating | C 0 |
5 216 lbf
|
Fatigue load limit | P u |
220 lbf
|
Limiting speed |
2 200 r/min
|
|
Limiting speed with shaft tolerance h6
|
||
Calculation factor | f 0 | 14
|
Mass
Mass |
1.742 lbs .
|
Mounting information
Set screw | G 2 | 3/8-24 UNF
|
---|---|---|
Hexagonal key size for set screw | N |
0.188 in
|
Recommended tightening torque for set screw |
146.037 lbf in.
|
Associated products
Rubber seating ring | RIS 210 A |
