ตลับลูกปืน SKF YAR 208-2LPW/SS

Name: ตลับลูกปืน SKF YAR 208-2LPW/SS
Brand: SKF
SKU: YAR208-2LPW/SS
Price: 3297.00 THB
Availability: InStock

SKF

3,297.00 ฿

Sale Sold out

Quantity

รายละเอียด ตลับลูกปืน SKF YAR 208-2LPW/SS

d	40 mm	Bore diameter
D	80 mm	Outside diameter
B	49.2 mm	Width of inner ring
C	21 mm	Width of outer ring
d₁	≈ 51.8 mm	Outside diameter of inner ring
B₄	10 mm	Distance face to thread centre
r_1,2	min. 1 mm	Chamfer dimension of inner ring
s₁	30.2 mm	Distance from locking device side face to raceway centre

Basic dynamic load rating	C	24.7 kN
Basic static load rating	C₀	19 kN
Fatigue load limit	P_u	0.8 kN
Limiting speed		2 800 r/min
		Limiting speed with shaft tolerance h6
Calculation factor	f₀	14

0.6 kg

Set screw	G₂	M8x1
Hexagonal key size for set screw	N	4 mm
Recommended tightening torque for set screw		6.5 N·m

Rubber seating ring
