SKF YAR bearing 207-106-2LPW/SS
SKF YAR bearing 207-106-2LPW/SS
Regular price
3,319.00 ฿
Regular price
Sale price
3,319.00 ฿
Unit price
per
SKF
Couldn't load pickup availability
รายละเอียด SKF YAR bearing 207-106-2LPW/SS
Dimensions
| d |
34.925 mm
|
Bore diameter |
|---|---|---|
| D |
72 mm
|
Outside diameter |
| B |
42.9 mm
|
Width of inner ring |
| C |
19 mm
|
Width of outer ring |
| d 1 |
≈ 46.1 mm
|
Outside diameter of inner ring |
| B 4 |
6 mm
|
Distance face to thread center |
| r 1,2 |
min. 1 mm
|
Chamfer dimension of inner ring |
| s 1 |
25.4 mm
|
Distance from locking device side face to raceway center |
Calculation data
| Basic dynamic load rating | C |
21.6 kN
|
|---|---|---|
| Basic static load rating | C 0 |
15.3 kN
|
| Fatigue load limit | P u |
0.655 kN
|
| Limiting speed |
3 200 r/min
|
|
Limiting speed with shaft tolerance h6
|
||
| Calculation factor | f 0 | 14
|
Mass
| Mass |
0.45 kg
|
Mounting information
| Set screw | G 2 | 5/16-24 UNF
|
|---|---|---|
| Hexagonal key size for set screw | N |
3.969 mm
|
| Recommended tightening torque for set screw |
6.5 N m
|
Associated products
| Rubber seating ring | RIS 207 A |
