ตลับลูกปืน SKF YAR 205-100-2LPW/SS

Name: ตลับลูกปืน SKF YAR 205-100-2LPW/SS
Brand: SKF
SKU: YAR205-100-2LPW/SS
Price: 2417.00 THB
Availability: InStock

SKF

2,417.00 ฿

Sale Sold out

Quantity

รายละเอียด ตลับลูกปืน SKF YAR 205-100-2LPW/SS

d	25.4 mm	Bore diameter
D	52 mm	Outside diameter
B	34.1 mm	Width of inner ring
C	15 mm	Width of outer ring
d₁	≈ 33.74 mm	Outside diameter of inner ring
B₄	5 mm	Distance face to thread centre
r_1,2	min. 0.6 mm	Chamfer dimension of inner ring
s₁	19.8 mm	Distance from locking device side face to raceway centre

Basic dynamic load rating	C	11.9 kN
Basic static load rating	C₀	7.8 kN
Fatigue load limit	P_u	0.335 kN
Limiting speed		4 300 r/min
		Limiting speed with shaft tolerance h6
Calculation factor	f₀	14

0.19 kg

Set screw	G₂	1/4-28 UNF
Hexagonal key size for set screw	N	3.175 mm
Recommended tightening torque for set screw		4 N·m

Rubber seating ring
