TL-W3 Inductive Sensors
Features and benefits
Space saving, low profile rigid aluminium die cast housing
All provided with an operation indicator
Mounting front or rear of the housing
Protected from water or oil splashes
Standards
IEC IP67
Specifications
| คุณสมบัติ |
Value |
| Sensor Technology |
Inductive |
| Body Style |
Block |
| Output Type |
PNP |
| Detection Range |
3 mm |
| Terminal Type |
Cable |
| Supply Voltage |
12 → 24 V dc |
| IP Rating |
IP67 |
| Length |
27mm |
| Width |
10mm |
| Depth |
6mm |
| Maximum DC Voltage |
30V |
| Mounting Type |
Flush |
| Switching Current |
100 mA |
| Shielding |
Unshielded |
| Maximum Switching Frequency |
600Hz |
| Maximum Operating Temperature |
+70°C |
| Housing Material |
ABS |
| Minimum Operating Temperature |
-25°C |
| Reverse Polarity Protection |
Yes |
