โซลินอยด์วาล์ว SMC 5/3 Pilot/Pilot G 1/4 SY7000 Series 24V dc

โซลินอยด์วาล์ว SMC 5/3 Pilot/Pilot G 1/4 SY7000 Series 24V dc

SMC

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
4,529.00 ฿
4,529.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด โซลินอยด์วาล์ว SMC 5/3 Pilot/Pilot G 1/4 SY7000 Series 24V dc

  • The SY series are 5 port solenoid valves, they are an interface between electronic controllers and pneumatic systems. These solenoid valves are smaller and have a higher flow. The SY3000 series offers the user different sized valves which are mounted on the same manifold. The SY series of solenoid valves is more reliable offering the user enhanced performance. Another advantage of the SY series is the reduced power consumption offering the user lower operational costs.
Specifications
Manufacturer Series SY7000
Mounting Style Stand-Alone
Function 44684
Connection Port Thread G 1/4
Actuation Type Pilot/Pilot
Solenoid Fitted Yes
Body Material Die Cast Aluminium
Maximum Flow Rate 912.8NL/min
Solenoid Voltage 24V dc
Solenoid Power Consumption 0.35W
Minimum Operating Pressure 0.2MPa
Minimum Operating Temperature -10°C
Maximum Operating Pressure 0.7 MPa
Number of Ports 44684
Thread Size 1/4in
Maximum Operating Temperature +50°C
Thread Standard G
