โซลินอยด์วาล์ว SMC 5/2 Spring/Solenoid Rc 1/8 VZ5000 Series 24V dc

Name: โซลินอยด์วาล์ว SMC 5/2 Spring/Solenoid Rc 1/8 VZ5000 Series 24V dc
Brand: SMC
Price: 4432.00 THB
Availability: InStock

SMC

4,432.00 ฿

ลดราคา ขายหมดแล้ว

ปริมาณ

รายละเอียด โซลินอยด์วาล์ว SMC 5/2 Spring/Solenoid Rc 1/8 VZ5000 Series 24V dc

Low power consumption SMC Series VZ500 solenoid valves. The VZ500 valve can be used within a vacuum. The valve can also be used as a selector valve of a divider valve.

Specifications
Manufacturer Series	VZ5000
Mounting Style	Stand-Alone
Function	44683
Connection Port Thread	Rc 1/8
Actuation Type	Spring/Solenoid
Solenoid Fitted	Yes
Body Material	Die Cast Aluminium
Maximum Flow Rate	588NL/min
Solenoid Voltage	24V dc
Solenoid Power Consumption	75W
Minimum Operating Pressure	0.15MPa
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+50°C
Thread Size	1/8in
Maximum Operating Pressure	0.7 MPa
Number of Ports	44683
Thread Standard	Rc
