โซลินอยด์วาล์ว SMC 5/2 Solenoid/Pilot G 1/8 VZ5000 Series 24V dc

Name: โซลินอยด์วาล์ว SMC 5/2 Solenoid/Pilot G 1/8 VZ5000 Series 24V dc
Brand: SMC
Price: 6703.00 THB
Availability: InStock

SMC

6,703.00 ฿

ลดราคา ขายหมดแล้ว

ปริมาณ

รายละเอียด โซลินอยด์วาล์ว SMC 5/2 Solenoid/Pilot G 1/8 VZ5000 Series 24V dc

Range of 5//2 and 5//3 valves with pneumatic or electrical control for in-line mounting.
Connector to be ordered separately.
Manual pulse control.

Specifications
Manufacturer Series	VZ5000
Mounting Style	Stand-Alone
Function	44683
Connection Port Thread	G 1/8
Actuation Type	Solenoid/Pilot
Solenoid Fitted	Yes
Body Material	Die Cast Aluminium
Maximum Flow Rate	588NL/min
Solenoid Voltage	24V dc
Solenoid Power Consumption	2.1W
Minimum Operating Pressure	0.1MPa
Minimum Operating Temperature	-10°C
Number of Ports	44683
Maximum Operating Temperature	+50°C
Thread Size	1/8in
Maximum Operating Pressure	0.7 MPa
Thread Standard	G
