โซลินอยด์วาล์ว SMC 3/2 Solenoid G 1/8 VT307 Series 110V ac

Name: โซลินอยด์วาล์ว SMC 3/2 Solenoid G 1/8 VT307 Series 110V ac
Brand: SMC
Price: 1983.00 THB
Availability: InStock

SMC

1,983.00 ฿

ลดราคา ขายหมดแล้ว

ปริมาณ

รายละเอียด โซลินอยด์วาล์ว SMC 3/2 Solenoid G 1/8 VT307 Series 110V ac

SMC have updated their EVT307 valve range with the new VT307 series. These new direct acting solenoid valves offer reduced power consumption over existing models and are available with both vacuum and energy-saving versions. Available with voltage surge suppression. Suitable for a diverse range of applications including
Blow-of valves, Pressure release valves, single acting cylinder drives, Divider valves and double acting cylinder drives.

Specifications
Manufacturer Series	VT307
Mounting Style	Manifold
Function	44622
Connection Port Thread	G 1/8
Actuation Type	Solenoid/Solenoid
Solenoid Fitted	Yes
Body Material	Die Cast Aluminium
Solenoid Voltage	110V ac
Solenoid Power Consumption	4 W, 4.2W
Minimum Operating Pressure	0MPa
Minimum Operating Temperature	-10°C
Thread Size	1/8in
Maximum Operating Temperature	+50°C
Maximum Operating Pressure	0.7 MPa
Number of Ports	44622
Thread Standard	G
