| Part | Material | Size |
|---|---|---|
| Body | Bronze BS EN 1982 CC491K | All |
| Bonnet | Bronze BS EN 1982 CC491K | All |
| Disc | Brass BS EN 12164 CW614N | 1/4 - 1 1/2 |
| Disc | Bronze BS EN 1982 CC491K | 2 |
| Stem | Brass BS EN 12164 CW614N | All |
| Packing | Asbestos Free | All |
| Gland | Brass BS EN 12164 CW614N | All |
| Packing Nut | Brass BS EN 12164 CW614N | All |
| Disc Stem Ring | Manganese Bronze BS EN 12164 CW721R | 2 Only |
| Handwheel | Aluminium | All |
| Handwheel Nut | Brass BS EN 12164 CW614N | All |
| ID Plate | Aluminium | All |
Dimensions & Weights
| SIZE(mm) | WEIGHT(Kg) | A(mm) | B(mm) | C(mm) |
|---|---|---|---|---|
| 1/4 | 0.23 | 44 | 75 | 52 |
| 3/8 | 0.22 | 44 | 75 | 52 |
| 1/2 | 0.31 | 55 | 82 | 52 |
| 3/4 | 0.42 | 63 | 89 | 52 |
| 1 | 0.71 | 77 | 102 | 65 |
| 1 1/4 | 1.12 | 91 | 118 | 70 |
| 1 1/2 | 1.5 | 98 | 134 | 78 |
| 2 | 2.48 | 118 | 171 | 103 |
