Turck Inductive Block-Style Proximity Sensor รหัส BI20U-CA40-AP6X2-H1141
Turck Inductive Block-Style Proximity Sensor รหัส BI20U-CA40-AP6X2-H1141
TURCK
กรุณาตรวจสอบสต็อกก่อนชำระเงินราคาปกติ
2,938.00 ฿
ราคาปกติ
3,457.00 ฿
ราคาโปรโมชัน
2,938.00 ฿
ราคาต่อหน่วย
/
ต่อ
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
รายละเอียด Turck Inductive Block-Style Proximity Sensor รหัส BI20U-CA40-AP6X2-H1141
Stubby Cube
PBT housing and sensing face. Stock number 405-7167
has a metal housing with duroplast sensing face providing high impact and thermal resistance
Adjustable sensing head, 5 positions
M12 connector termination. Supplied with 2m PUR single-ended, straight connector lead
3 wire dc
Yellow LED output status display
Green LED for power on, flashing indicates a short circuit
Mounting bracket included
has a metal housing with duroplast sensing face providing high impact and thermal resistance
Adjustable sensing head, 5 positions
M12 connector termination. Supplied with 2m PUR single-ended, straight connector lead
3 wire dc
Yellow LED output status display
Green LED for power on, flashing indicates a short circuit
Mounting bracket included
Uprox Range
Extended sensing ranges
Sense all metals at the same distance - with no reduction factor
IP67 rating (Barrel is IP68)
High switching frequency
No load current 15mA max.
Operating Temperature Range -25 → +85°C
Short circuit protection Overload protection
Reverse polarity protection
Inherent weld field immunity
Sense all metals at the same distance - with no reduction factor
IP67 rating (Barrel is IP68)
High switching frequency
No load current 15mA max.
Operating Temperature Range -25 → +85°C
Short circuit protection Overload protection
Reverse polarity protection
Inherent weld field immunity
คุณสมบัติ |
Value |
|---|---|
| Body Style | Block |
| Sensor Technology | Inductive |
| Output Type | PNP-NO |
| Detection Range | 20 mm |
| Terminal Type | M12 - 4 Pin |
| Supply Voltage | 10 → 30 V dc |
| IP Rating | IP67 |
| Length | 65mm |
| Width | 40mm |
| Depth | 40mm |
| Maximum DC Voltage | 30V |
| Mounting Type | Flush Mount |
| Switching Current | 200 mA |
| Maximum Switching Frequency | 250Hz |
| Maximum Operating Temperature | +70°C |
| Housing Material | Gadolinium Aluminium |
| Reverse Polarity Protection | Yes |
| Minimum Operating Temperature | 0°C |
| Short Circuit Overload Protection | Yes |
