• SIEMENS Timer Relay 3RA2812-2DW10
1 1

SIEMENS Timer Relay 3RA2812-2DW10

SIEMENS Timer Relay 3RA2812-2DW10

SIEMENS

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
4,111.00 ฿
4,111.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด SIEMENS Timer Relay 3RA2812-2DW10

The Siemens SIRIUS 3RA28 electronic time relay is a function module for switching operations involving time delays in control, starting, protection and regulation circuits. It performs the function of providing supply initiated with On delay in the time range between 0.05s and 100 s. The simple plug-in facility requires no tools and permits the implementation of controller-independent time functions without any additional wiring.

Screw or spring-loaded termination
Selectable outputs 1 NO + 1 NC or 1 C
IEC, CCC, UL CSA approved
คุณสมบัติ Value
Supply Voltage 240V ac
Mounting Type Clip-On
Number of Contacts 6
Time Range 0.05 → 100s
Mode of Operation One Shot
Number of Timer Functions Single
Time Increment Seconds
Maximum Voltage 240V
Series 3RA28
Terminal Type Cage Clamp
Minimum Voltage 240V
Width 45mm
Maximum Operating Temperature +60°C
Length 74mm
Depth 38mm
Time Delay 50ms
Minimum Operating Temperature -25°C
