Dimensions
| Size | Dimension (mm) | Flow area (mm 2) | Weight(Kg.) | ||||
|---|---|---|---|---|---|---|---|
| d | L | H 1 | H | Seat diameter | |||
| 15A | Rc 1/2 | 34 | 40 | 126 | 16 | 20.1 | 0.7 |
| 20A | Rc 3/4 | 38 | 43 | 126.5 | 21 | 34.6 | 0.8 |
| 25A | Rc 1 | 43 | 51.5 | 142.5 | 26 | 53.0 | 1.1 |
| 32A | Rc 1 1/4 | 50 | 61.5 | 179.5 | 33 | 93.3 | 1.8 |
| 40A | Rc 1 1/2 | 60 | 60 | 203 | 41 | 135.2 | 2.8 |
| 50A | Rc 2 | 75 | 76 | 243.5 | 51 | 208.2 | 4.7 |
