TL-W Standard Flat Inductive Sensors
The TL-W series are standard flat inductive proximity sensors. These sensors are only 6 mm thick yet provide a sensing distance of up to 5mm.
Features and benefits
Pre wired models with 2m cable
Heat resistant ABS casing
Protection circuit: load short circuit protection, surge suppressor
Temperature range -25 → 70 °C
IP67 ingress protection
The Omron proximity sensor is a inductive, DC 3-wire model has 5 mm sensing distance, unshielded type with NPN output.
Electrical connection - 2 m PVC cable
Normally closed (NC) contact configuration
Specifications
| คุณสมบัติ |
Value |
| Sensor Technology |
Inductive |
| Body Style |
Block |
| Output Type |
NPN |
| Detection Range |
5 mm |
| Terminal Type |
Cable |
