Proximity Sensor OMRON E2E-S05S12-WC-B1 2M
Proximity Sensor OMRON E2E-S05S12-WC-B1 2M
OMRON
กรุณาตรวจสอบสต็อกก่อนชำระเงินราคาปกติ
3,249.00 ฿
ราคาปกติ
ราคาโปรโมชัน
3,249.00 ฿
ราคาต่อหน่วย
/
ต่อ
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
รายละเอียด Proximity Sensor OMRON E2E-S05S12-WC-B1 2M
E2E Small Diameter Proximity Sensors
The E2E inductive proximity sensors are extremely small in diameter with 3mm, 4mm, 6.5 mm, M4 and M5 versions available. The stable long sensing distance of these sensors enables high performance for detection of ferrous metal even when the work flow is unsteady. The E2E series of proximity sensors have 4 indicator lamps on them in a 360 ° layout making it extremely easy to check the operation status.
High speed response enables sharp detection timing, 5 kHz max
Load short-circuit protection and output reverse polarity protection
Easy installation
LED indication
Load short-circuit protection and output reverse polarity protection
Easy installation
LED indication
Note
See typically (RS stock no. 7788757) for connectors compatible with the plug-in sensors
Specifications
| คุณสมบัติ | Value |
| Sensor Technology | Inductive |
| Body Style | Barrel |
| Thread Size | M5 x 0.5 |
| Output Type | PNP-NO |
| Detection Range | 1.2 mm |
| Terminal Type | Cable |
| IP Rating | IP67 |
| Supply Voltage | 10 → 30 V dc |
| Length | 25.1mm |
| Maximum DC Voltage | 30V |
| Mounting Type | Flush Mount |
| Switching Current | 100 mA |
| Maximum Operating Temperature | +70°C |
| Housing Material | Stainless Steel |
| Maximum Switching Frequency | 4kHz |
| Shielding | Shielded |
| Reverse Polarity Protection | Yes |
| Minimum Operating Temperature | -25°C |
| Short Circuit Overload Protection | Yes |
