Proximity Sensor OMRON E2A-M12KS04-WP-C1 5M
Proximity Sensor OMRON E2A-M12KS04-WP-C1 5M
OMRON
กรุณาตรวจสอบสต็อกก่อนชำระเงินราคาปกติ
2,184.00 ฿
ราคาปกติ
ราคาโปรโมชัน
2,184.00 ฿
ราคาต่อหน่วย
/
ต่อ
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
รายละเอียด Proximity Sensor OMRON E2A-M12KS04-WP-C1 5M
E2A Standard Length Brass
Features and benefits
PBTP sensing face material
LED indication
Exceeds CENELEC sensing range for greater sensitivity and mechanical protection
Standard range is a replacement to short body and E2EG range
Operating temperature range -40 → +70°C
Supply voltage 12 to 24Vdc
Load current 200mA maximum
Short circuit, surge suppression and reverse polarity protection
CENELEC range to EN60947-5-2
LED indication
Exceeds CENELEC sensing range for greater sensitivity and mechanical protection
Standard range is a replacement to short body and E2EG range
Operating temperature range -40 → +70°C
Supply voltage 12 to 24Vdc
Load current 200mA maximum
Short circuit, surge suppression and reverse polarity protection
CENELEC range to EN60947-5-2
Applications
Sensing and instrumentation
Note
The non-shielded units cannot be flush mounted or embedded in metal without adversely affecting performance. For flush mounting please choose a shielded version.
Note
See typically (RS stock no. 7788757) for connectors compatible with the plug-in sensors
Specifications
| คุณสมบัติ | Value |
| Sensor Technology | Inductive |
| Body Style | Barrel |
| Thread Size | M12 x 1 |
| Output Type | NPN |
| Detection Range | 4 mm |
| Terminal Type | Cable |
| Supply Voltage | 12 → 24 V dc |
| IP Rating | IP67 |
| Length | 34mm |
| Maximum DC Voltage | 32V |
| Mounting Type | Flush |
| Switching Current | 200 mA |
| Shielding | Shielded |
| Maximum Operating Temperature | +70°C |
| Housing Material | Brass |
| Maximum Switching Frequency | 1kHz |
| Reverse Polarity Protection | Yes |
| Minimum Operating Temperature | -40°C |
