• Omron Photoelectric Sensor E3H2-T4B4M 2M
1 1

Omron Photoelectric Sensor E3H2-T4B4M 2M

Omron Photoelectric Sensor E3H2-T4B4M 2M

OMRON

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
6,688.00 ฿
6,688.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด Omron Photoelectric Sensor E3H2-T4B4M 2M

E3H2 Miniature Sensors

Retro-reflective models with two teaching modes for standard and transparent objects
Reverse polarity and short-circuit protection
Maximum switching current: 45 mA
Operating temperature range: -20 → +55 °C

E3F2 Series Barrel

Output can be configured by wiring either ’light ON’ or ’dark ON’
Built in amplifier
Short circuit and reverse polarity protection
M18 DIN size cylindrical housing
คุณสมบัติ Value
Sensor Style Barrel
Detection Type Through Beam (Emitter and Receiver)
Detection Range 4 m
Output Type PNP
Electrical Connection Pre-Wired Cable
Maximum DC Voltage 30V
Light Source Infrared
IP Rating IP67
Maximum Current 100 mA
Response Time 2.5 ms
Maximum Operating Temperature +55°C
Housing Material Nickel Plated Brass
Series E3H2
Minimum Operating Temperature -25°C
