Omron limit switch Z-15GD55-B

Omron limit switch Z-15GD55-B

รูปสินค้าอาจไม่ตรงกับของจริง รบกวนสอบถามแอดมินเพื่อขอดูรูปเพิ่มเติม

OMRON

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
603.00 ฿
603.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด Omron limit switch Z-15GD55-B

Z15 Series – Basic Switch


The Z series of basic switches from Omron are in plastic housing however still provide the same electrical and mechanical switching capability and lifetime as standard limit switches. These basic switches are ideal for use in uncritical environments or when separately encased in subassemblies.

High precision basic switch in a wide range of variations
Large switching capacity of 15A with high repeat accuracy
Contact configuration: SPDT
Contact rating: 250Vac 15A, 14Vdc 15A
Contact Gap either 0.5mm (Standard) or 1.8mm (High Capacity)

Approvals

UL recognised, CSA
The Omron General-purpose basic switch has a large switching capacity of 15 A with high repeat accuracy. It has a wide range of variations in contact form basic, split-contact, maintained-contact, and adjustable contact gap types.

Degree of protection equivalent to IP62
Operating temperature −25°C to 80°C

For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.


คุณสมบัติ
Value
Actuator Type Spring Plunger
Pole and Throw Configuration SPDT
Normal State Configuration NO/NC
IP Rating IP62
Maximum Current 15A
Housing Material Plastic
Maximum AC Voltage 500V ac
Series Z
