Omron limit switch DZ-10GW-1B

The DZ series limit switches have a DPDT basic switch for two independent circuit controls. They incorporates two completely independent built-in switches and are ideal for switching circuits on two different voltages of for controlling two independent circuits. They are also interchangeable with Omron Z basic switches, as both switches are identical in mounting hole dimensions, mounting pitch and pin plunger position.

Contact rated for a wide range of voltages
Contact current rating: 10A at 250 Vac
Operating temperature Range: -25 to +80 °C (with no icing)
Mechanical service life: 1,000,000 operations minimum
Electrical service life: 500,000 operations minimum

This limit switch is designed to offer precise control in various automation and industrial applications. With a lever actuator, it enables flexibility and accuracy in operation, making it a crucial component for effective machinery management. Its robust design meets the needs of both electrical and mechanical sectors while ensuring consistent performance under demanding conditions.

• Snap action mechanism improves operational efficiency
• DPDT configuration provides versatile switching options
• Operating temperature range of -25 to +85°C for adaptability
• Screw connection type allows for simple and secure installation

• Suitable for machinery safety interlocks
• Utilised in automated production lines for accurate control
• Used in conveyor systems to detect positioning
• Employed in robotic systems for motion control

Ensure it is mounted securely in the correct orientation, using the screw connection for stability.

It functions effectively within a temperature range of -25 to +85°C, ensuring reliability in varied environments.

Yes, it is rated for a maximum current of 10A, making it appropriate for numerous applications.
