• Carlo Gavazzi Through Beam Photoelectric Sensor Code ET1820PPAS-1
1 1

Carlo Gavazzi Through Beam Photoelectric Sensor Code ET1820PPAS-1

Carlo Gavazzi Through Beam Photoelectric Sensor Code ET1820PPAS-1

CARLO GAVAZZI

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
3,998.00 ฿
4,997.00 ฿ 3,998.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด Carlo Gavazzi Through Beam Photoelectric Sensor Code ET1820PPAS-1

ET Series Through-Beam Sensors


Carlo Gavazzi ET series general purpose through-beam sensors in an industrial standard M18 nickel-plated brass housing for heavy duty applications. They are useful for simple applications where a basic sensor provide adequate sensing performance. The sensors are easy to adjust with a 270° single turn potentiometer. The output is a 4-wire complementary (NO and NC) circuit with NPN (current sinking) or PNP (current sourcing) open collector transistor output.

Long 20 m Range
Adjustable sensitivity
Modulated infrared light
Make and break switching functions, NPN, PNP (200 mA)
LED-indication for power supply ON (emitter) and target detected (receiver)
Supply voltage: 10 to 40 VDC
Heavy duty M18 metal housing, IP 67
Cable and plug versions

Note

Emitter and receiver must be ordered separately.


Carlo Gavazzi Photoelectric Sensors
คุณสมบัติ
Value
Sensor Style Barrel
Detection Type Through Beam
Detection Range 20 m
Output Type PNP
Electrical Connection M12 Connector
Maximum DC Voltage 40V
Terminal Type M12 Connector
Light Source LED
IP Rating IP67
Maximum Current 12 mA
Response Time 4.2 ms, <1.6 ms
Maximum Operating Temperature +60°C
Housing Material Nickel Plated Brass
Minimum Operating Temperature -20°C

Datasheet - ET1820PPAS-1
