Carlo Gavazzi Inductive Barrel-Style Proximity Sensor Code ICB30L50N22A2IO
Carlo Gavazzi Inductive Barrel-Style Proximity Sensor Code ICB30L50N22A2IO
CARLO GAVAZZI
กรุณาตรวจสอบสต็อกก่อนชำระเงินราคาปกติ
1,962.00 ฿
ราคาปกติ
2,452.00 ฿
ราคาโปรโมชัน
1,962.00 ฿
ราคาต่อหน่วย
/
ต่อ
ไม่สามารถโหลดความพร้อมในการรับสินค้าด้วยตนเองได้
รายละเอียด Carlo Gavazzi Inductive Barrel-Style Proximity Sensor Code ICB30L50N22A2IO
The output can be operated either as a switching output or in IO-Link mode
Fully configurable via IO-Link v1.1. Electrical outputs can be configured as PNP/NPN/Push-pull, normally open or normally closed
Timer functions can be set, such as switch-on and switch-off delay
Adjustable sensing distance and hysteresis: sensing distance can be set to 33%, 50%, 75% or 100% of the maximum sensing distance
Temperature monitoring: over or under-run temperature alarms can be set
Applications
Non contact detection of metal objects in general position-sensing and presence-sensing in industrial applications
Particularly suitable for rotational speed monitoring thanks to the high operating frequency
Fully configurable via IO-Link v1.1. Electrical outputs can be configured as PNP/NPN/Push-pull, normally open or normally closed
Timer functions can be set, such as switch-on and switch-off delay
Adjustable sensing distance and hysteresis: sensing distance can be set to 33%, 50%, 75% or 100% of the maximum sensing distance
Temperature monitoring: over or under-run temperature alarms can be set
Applications
Non contact detection of metal objects in general position-sensing and presence-sensing in industrial applications
Particularly suitable for rotational speed monitoring thanks to the high operating frequency
คุณสมบัติ |
Value |
|---|---|
| Sensor Technology | Inductive |
| Thread Size | M30 x 1.5 |
| Body Style | Barrel |
| Output Type | PNP & NPN IO-LINK |
| Detection Range | 22 mm |
| Terminal Type | Cable |
| Supply Voltage | 10 → 36 V dc |
| IP Rating | IP67 |
| Length | 64mm |
| Communication Protocol | IO-LINK |
| Maximum DC Voltage | 36V |
| Mounting Type | Non-Flush |
| Switching Current | 200 mA |
| Maximum Operating Temperature | +70°C |
| Housing Material | Brass |
| Maximum Switching Frequency | 1kHz |
| Minimum Operating Temperature | -25°C |
| Short Circuit Overload Protection | Yes |
| Reverse Polarity Protection | Yes |
Datasheet - ICB30L50N22A2IO
