Burkert Solenoid Valve 134092, 2 port(s) , NC, 24 V ac, 1/8inRS Stock No.:307-0260หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:134092

Burkert Solenoid Valve 134092, 2 port(s) , NC, 24 V ac, 1/8inRS Stock No.:307-0260หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:134092

Burkert

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
ราคาปกติ 2,761.00 ฿
ราคาปกติ 3,451.00 ฿ ราคาโปรโมชัน 2,761.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด Burkert Solenoid Valve 134092, 2 port(s) , NC, 24 V ac, 1/8inRS Stock No.:307-0260หมายเลขชิ้นส่วนของผู้ผลิต / Mfr. Part No.:134092

2 // 2 NF direct control, miniature solenoid valves, series 6011

Range of miniature, modular 2//2 solenoid valvesDirect control NF for neutral liquids up to +100°C.
G1/8' threaded body connection.
Able to change the solenoid without removing the valve.
The solenoid can be positioned freely or locked in 4 positions at 90° intervals.
High-quality, FPM sealing materials included as standard (Viton).
DIN 43650C Connector
Brass body.
Compact solenoid valves suitable for most gas and fluid handling applications. Where practical, valves are shown with a schematic diagram showing the (circuit) function. The diagram is laid out so that the left-hand side of the diagram describes the valves operation when the coil is energised. When the coil is de-energised, the spring (or servo-assist) return controls the valve and is described on the right-hand side of the diagram. The 3 / 2-way designation indicates a valve with three ports and two modes of operation. It is normal practice to refer to 2 / 2-way valves as two ways. The port designations A, B, P, P1, P2 and R are used on the schematic diagrams and are marked on the valve bodies. Valve bodies are marked for a specific circuit function but can often be used for other functions. Reference to the schematic diagrams and technical specifications indicates the appropriate connections and pressure capabilities when an alternative circuit function is required.
คุณสมบัติ Value
Supply Voltage 24 V ac
Number of Ports 2
Connection Size 1/8in
Connection 1/8 in G Female
Operation Direct
Default Valve Position NC
Suitable Applications Liquid, Neutral Gas, Technical Vacuum
Type 2/2
Orifice Diameter 1.6mm
Series 6011
Body Material Brass
Maximum Working Pressure 12 bar
Operating Temperature Range Maximum of +55 °C
Connection Gender Female
Maximum Operating Temperature +55°C
Thread Standard or Connection Type G
Flow Factor Kv 0.06m³/h
Maximum Opening Time 10ms
Maximum Closing Time 15ms
