รายละเอียด Baumer BTIV Series Optical Incremental Encoder Code BTIV 24S 16.24K 1024 G4 5
Features
- miniature shaft encoder
- high resolution up to 1024 pulses
- housing diameter 24 mm
| General Data | |
|---|---|
| Voltage supply | 5 VDC ±5% (05T) 10 - 30 VDC (24K) |
| max. supply current | typ. 25 mA (at 5 VDC) (05T) no load typ. 25 mA (at 24 VDC) (24K) |
| pulse range | see order designation |
| pulse tolerance | ±10% at 30 kHz |
| max. switching frequency | 100 kHz |
| Mechanical Data | |
|---|---|
| max. revolutions | 18'000 rpm |
| torque | max. 0,6 cNm (20 °C) |
| max. shaft load | axial: 5 N radial: 8 N |
| max. protection class | shaft: IP 54 housing: IP 54 |
| material | housing: aluminum |
| weight | approx. 50 g |
