• ลูกปืนตุ๊กตา INA PME50-XL-N
1 1

ลูกปืนตุ๊กตา INA PME50-XL-N

ลูกปืนตุ๊กตา INA PME50-XL-N

INA

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
5,364.00 ฿
5,364.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด ลูกปืนตุ๊กตา INA PME50-XL-N

Flanged Housing Units with Centring Spigot

These flanged housing units have four bolts and a centring spigot which is mounted in a turned recess into the machine structure. The centring spigot gives concentric alignment of the housings and relieves the fixing screws of any radial forces.

Features and Benefits

• Cast iron

• Centring spigot

• Eccentric locking collar

• P seals

• Four-bolt units

Product Application Information

The units are used predominantly as locating bearings, but are also suitable as non-locating bearings under low loads and speeds.

Suffixes

N - Cast iron housing with undercut slot for end caps

คุณสมบัติ / Specifications

คุณสมบัติ Value
Material Cast Iron
Bearing Unit Type Flange Bearing Unit
Inside Diameter 50mm
Width 165mm
Depth 43.8mm
Number of Mount Holes 4
Mount Hole Size 14mm
