• ตลับลูกปืน INA RCSMB20/65FA106
1 1

ตลับลูกปืน INA RCSMB20/65FA106

ตลับลูกปืน INA RCSMB20/65FA106

INA

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
1,774.00 ฿
1,774.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด ตลับลูกปืน INA RCSMB20/65FA106

Radial Insert Ball Bearings with Rubber Interliner

INA from Schaeffler radial insert ball bearings with rubber interliners are on the shaft using an eccentric locking collar. The outer ring is encased in a thick-walled NBR interliner which absorbs vibrations and shocks. The interliners have either a spherical or cylindrical outside surface.

The P seal is two zinc-coated sheet steel washers with intermediate NBR part, seal lip axially preloaded.

To protect the seal lip from mechanical damage, the outer sheet steel washer extends a considerable distance down towards the bearing inner ring.

Used in narrow radial insert ball bearings with inner ring extended on one side.

Features and Benefits

• Lower operating costs

• Reduced maintenance due to improved lubrication

• Lower heat generation

• Less noise

• Inner ring and locking collar have anti-corrosion protection

• Shaft diameters from 12 mm to 50 mm (RABRB)

• Shaft diameters 20 mm (RCRA) 25 mm (RCRB)

• Shaft diameters 30 mm (RCSMA) 15 mm to 25 mm (RCSMB)

Product Application Information

Bearings with rubber interliners cannot be lubricated.

Suffixes

FA106 - Bearing subjected to special noise testing

คุณสมบัติ / Specifications

คุณสมบัติ Value
Inside Diameter 20mm
Outside Diameter 65.1mm
Ball Bearing Type Radial
Race Width 25.4mm
End Type Sealed
Number of Rows 1
Static Load Rating 6600N
Material Steel
Race Type Plain
Dynamic Load Rating 13600N
Bore Type Parallel
