ตลับลูกปืนตาเหลือก THK NOS3T

Name: ตลับลูกปืนตาเหลือก THK NOS3T
Brand: THK
Price: 280.00 THB
Availability: InStock

THK

280.00 ฿

ลดราคา ขายหมดแล้ว

ปริมาณ

รายละเอียด ตลับลูกปืนตาเหลือก THK NOS3T

Model No.	Outer dimensions			ThreadedS₁JIS Class 2	Holder dimensions			Spherical inner ring dimensions				Permissible tilt angles			Applied static loadRadialC_s	Mass
	LengthL	DiameterD	WidthB₁0-0.1		B±0.1	L₁	l	dH7	Ball diameter Da	d₁	C	α₁°	α₂°	α₃°
	LengthL	DiameterD	WidthB₁0-0.1		B±0.1	L₁	l	dH7	Ball diameter Da	d₁	C	α₁°	α₂°	α₃°
	mm	mm	mm		mm	mm	mm	mm	mm (inch)	mm	mm	degree	degree	degree	N	g
NOS3T	33	12	6	M3×0.5	4.5	27	15	3	9.525(3/8)	7.4	0.3	8	10	42	1570	4.5
NOS4T	37	14	7	M4×0.7	5.3	30	17	4	10.319(13/32)	7.6	0.3	9	11	35	2250	7
NOS5T	41	16	8	M5×0.8	6	33	20	5	11.112(7/16)	7.7	0.3	8	13	30	3430	12.5
NOS6T	45	18	9	M6×1	6.75	36	22	6	12.7(1/2)	9	0.3	8	13	30	4900	19
NOS8T	53	22	12	M8×1.25	9	42	25	8	15.875(5/8)	10.4	0.5	8	14	25	6860	32
NOS10T	61	26	14	M10×1.5	10.5	48	29	10	19.05(3/4)	12.9	0.5	8	14	25	9410	54
NOS12T	69	30	16	M12×1.75	12	54	33	12	22.225(7/8)	15.4	0.5	8	13	25	11000	85
NOS14T	77	34	19	M14×2	13.5	60	36	14	25.4(1)	16.9	0.7	10	16	24	15200	126
NOS16T	85	38	21	M16×2	15	66	40	16	28.575(1 1/8)	19.4	0.7	9	15	24	20200	185
NOS18T	93	42	23	M18×1.5	16.5	72	44	18	31.75(1 1/4)	21.9	0.7	9	15	24	25200	260
NOS20T	101	46	25	M20×1.5	18	78	47	20	34.925(1 3/8)	24.4	0.7	9	15	24	27800	340
NOS22T	109	50	28	M22×1.5	20	84	51	22	38.1(1 1/2)	25.8	0.7	10	15	23	35900	435
