• ตลับลูกปืน INA SL045010PP
1 1

ตลับลูกปืน INA SL045010PP

ตลับลูกปืน INA SL045010PP

INA

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
7,109.00 ฿
7,109.00 ฿
ลดราคา ขายหมดแล้ว

รายละเอียด ตลับลูกปืน INA SL045010PP

Double Row Full Complement Cylindrical Roller Bearings

INA from Schaeffler bearings have solid outer and inner rings and rib-guided cylindrical rollers. Since these bearings have the largest possible number of rolling elements, they have high radial load carrying capacity, high rigidity and are suitable for compact designs. Due to the kinematic conditions, however, they do not achieve the high speeds that are possible when using cylindrical roller bearings with cage.

Cable sheave bearings (cylindrical roller bearings with snap ring grooves) are locating bearings. These bearings are rigid and can support moderate axial forces in both directions and high radial forces. They consist of solid outer and inner rings with ribs, rib-guided cylindrical rollers and sealing rings.

The outer rings have snap ring grooves for retaining rings. The inner rings are axially split, 1 mm wider than the outer rings and held together by a rolled-in steel strip.

Features and Benefits

• Lower operating costs

• Reduced maintenance due to improved lubrication

• Lower heat generation

• Less noise

Product Application Information

The bearings have higher load carrying capacity and longer life for the same dimensioning. In certain applications, a smaller bearing arrangement can be designed.

Suffixes

PP - Seals on both sides, for cable sheave bearings

คุณสมบัติ / Specifications

คุณสมบัติ Value
Inside Diameter 50mm
Outside Diameter 80mm
Roller Bearing Type Cylindrical
Race Width 40mm
Bore Type Parallel
Material Steel
Static Load Rating 151000N
Number of Rows 2
Dynamic Load Rating 102000N
End Type Sealed
Limiting Speed 2600rpm
Fatigue Limit Load 21700N
Maximum Speed - Grease 2600rpm
