Yesly Electronic Dimmer, Bluetooth Code. 152182300200

Product details / Product Details

Light dimming machine model 15.21.8.230.B300 has features:

• Control via Bluetooth: Supports Bluetooth Low Energy (BLE) with 128-bit encrypted connection.
• Set up via Finder YOU app: Compatible with iOS and Android.
• Control via buttons: Can be controlled via standard buttons, BEYON wireless buttons or 013.B9.
• Adjustable brightness up to 300 watts: Supports dimmable LED bulbs, dimmable fluorescent bulbs, halogen bulbs, transformers or electronic power supplies.

Additional functions:

• Soft dimming
• Status LED
• Trailing edge or Leading edge dimming mode
• 7 work setting options
• Supports various types of loads
• There is a system to protect against overheating and short circuit.

Other models available

• 15.21.8.230.0200: Basic model, no Bluetooth, supports dimming up to 300 watts.
• 15.21.9.024.B200: Wall-mounted version, supports 12-24 V DC LED bulbs (maximum 8 amperes).

Technical features:

• Brightness Control Device: Unable to install app.
• Size: 43x44.1x21.9 mm.
• Nominal voltage: 230 volts
• Electrical system: AC home electricity
• Technical details: Dimer for installation on a circular wall box. Works with AC household power, rated voltage 230 volts, works at 0.8 to 1.1 volts, ambient temperature -10 to +45 degrees Celsius.
• Installation type: Dimer installed on a round wall box.
