Turck Inductive Block-Style Proximity Sensor รหัส Bi15U-Q20-AP6X2
Turck Inductive Block-Style Proximity Sensor รหัส Bi15U-Q20-AP6X2
TURCK
กรุณาตรวจสอบสต็อกก่อนชำระเงินRegular price
3,397.00 ฿
Regular price
3,996.00 ฿
Sale price
3,397.00 ฿
Unit price
/
per
Couldn't load pickup availability
รายละเอียด Turck Inductive Block-Style Proximity Sensor รหัส Bi15U-Q20-AP6X2
Rectangular
Features and benefits
PBT housing and sensing face.
Side sensing-reduces housing depth.
2m PVC prewired and M8/M12 connector versions
Connector versions supplied with a 2m PUR single-ended, straight connector lead
3 wire DC
Yellow LED output status display
Green LED for power on, flashing indicates a short circuit
Uprox Range
Extended sensing ranges
Sense all metals at the same distance - with no reduction factor
IP67 rating (Barrel is IP68)
High switching frequency
No load current 15mA max.
Operating Temperature Range -25 → +85°C
Short circuit protection Overload protection
Reverse polarity protection
Inherent weld field immunity
Sense all metals at the same distance - with no reduction factor
IP67 rating (Barrel is IP68)
High switching frequency
No load current 15mA max.
Operating Temperature Range -25 → +85°C
Short circuit protection Overload protection
Reverse polarity protection
Inherent weld field immunity
คุณสมบัติ |
Value |
|---|---|
| Sensor Technology | Inductive |
| Body Style | Block |
| Output Type | PNP-NO |
| Detection Range | 15 mm |
| Terminal Type | Cable |
| IP Rating | IP67 |
| Supply Voltage | 10 → 30 V dc |
| Length | 42mm |
| Width | 40mm |
| Depth | 20mm |
| Maximum DC Voltage | 30V |
| Mounting Type | Flush Mount |
| Switching Current | 200 mA |
| Housing Material | PBT |
| Maximum Operating Temperature | +85°C |
| Maximum Switching Frequency | 250Hz |
| Minimum Operating Temperature | -30°C |
| Reverse Polarity Protection | Yes |
| Short Circuit Overload Protection | Yes |
