Temperature Controllers OMRON E5ED-RX4A6M-000
Temperature Controllers OMRON E5ED-RX4A6M-000
OMRON
กรุณาตรวจสอบสต็อกก่อนชำระเงินRegular price
14,985.00 ฿
Regular price
Sale price
14,985.00 ฿
Unit price
/
per
Couldn't load pickup availability
รายละเอียด Temperature Controllers OMRON E5ED-RX4A6M-000
E5ED Digital Temperature Controllers
E5ED series digital PID temperature controllers optimise control by detecting status changes and satisfy both productivity and quality in various applications.
Features and Benefits
48 x 96 mm
4-digit, three-level displays PV, SV and MV displayed at the same time
Functions specialised for packaging machines
Functions specialised for water-cooled extruders
Indication data (power ON time, ambient temperature and output On/Off count)
Draw-out structure for easy maintenance
4-digit, three-level displays PV, SV and MV displayed at the same time
Functions specialised for packaging machines
Functions specialised for water-cooled extruders
Indication data (power ON time, ambient temperature and output On/Off count)
Draw-out structure for easy maintenance
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
Omron - E5GC, E5CC, E5EC, E5AC, E5DC, E5CN & E5CB Ranges
Specifications
| คุณสมบัติ | Value |
| Output Type | Relay |
| Supply Voltage | 100 → 240 V ac |
| Size | 48 x 96mm |
| Number of Inputs | 2 |
| Number of Outputs | 1 |
| Minimum Operating Temperature | -10°C |
| Maximum Operating Temperature | +55°C |
| Temperature Range | -10 → +55 °C |
| Control Type | Temperature Control |
| Display Type | 11-Segment Digital Display |
| IP Rating | IP00, IP20, IP66 |
| Input Type | Analogue, Temperature |
| Range | Omron E5ED |
| Mounting Type | Panel Mount |
| Series | E5ED |
| Panel Depth | 62mm |
| Termination Type | Screw |
