Temperature Controllers OMRON E5EC-QX2DBM-000

Temperature Controllers OMRON E5EC-QX2DBM-000

รูปสินค้าอาจไม่ตรงกับของจริง รบกวนสอบถามแอดมินเพื่อขอดูรูปเพิ่มเติม

OMRON

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
12,378.00 ฿
12,378.00 ฿
Sale Sold out

รายละเอียด Temperature Controllers OMRON E5EC-QX2DBM-000

E5EC Digital Temperature Controllers (48 x 96mm)


Premium range of temperature controllers which support a wide variety of applications. The controllers cover a comprehensive array of sensor inputs including Universal, Thermocouple, PT and Analogue current/voltage. Within the E5EC range, there is a temperature controller to suit your requirements.
• Large white LCD display, 18 mm of height for best visibility
• Three level display- PV/SV/MV displayed at the same time with 4-digit display
• 50 ms sampling period time
• Extended range of I/O's: 4 auxiliary outputs, 6 event inputs, transfer output and remote SP's
• Short housing case with only 60 mm of depth
• Easy connection to PLC with communications that require no programming
• Component communications can be used to link temperature controllers to each other
• Tool ports provided both on top panel and front panel
• Easy set up with CX-Thermo software (Windows XP, 7) without additional power supply via USB conversion cable

Approvals

CE
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.

Omron - E5GC, E5CC, E5EC, E5AC, E5DC, E5CN & E5CB Ranges

Specifications

คุณสมบัติ Value
Output Type Voltage
Supply Voltage 24 V ac/dc
Size 48 x 96mm
Number of Inputs 3
Number of Outputs 1
Minimum Operating Temperature -10°C
Maximum Operating Temperature +55°C
Temperature Range +100 → +1800 (Type B Thermocouple) °C, 0 → +1300 (Type PLII Thermocouple) °C, 0 → +1700 (Type R Thermocouple) °C, 0 → +1700 (Type S Thermocouple) °C, 0 → +2300 (Type W Thermocouple) °C, -100 → +850 (Type J Thermocouple) °C, -100 → +850 (Type L Thermocouple) °C, -199.9 → +400 (Type T Thermocouple) °C, -199.9 → +400 (Type U Thermocouple) °C, -199.9 → +500 (JPt100) °C, -200 → +1300 (Type K Thermocouple) °C, -200 → +1300 (Type N Thermocouple) °C, -200 → +600 (Type E Thermocouple) °C, -200 → +850 (Pt100) °C
Display Type 11-Segment Digital Display
IP Rating IP00, IP20, IP66
Input Type Universal (Analogue), Universal (Pt), Universal (Thermocouple)
Range Omron E5EC
Series E5EC
Mounting Type Panel Mount
Panel Depth 59mm
Termination Type Screw
Display Colour White
