• Temperature Controllers OMRON E5CD-QX2A6M-002
1 1

Temperature Controllers OMRON E5CD-QX2A6M-002

Temperature Controllers OMRON E5CD-QX2A6M-002

รูปสินค้าอาจไม่ตรงกับของจริง รบกวนสอบถามแอดมินเพื่อขอดูรูปเพิ่มเติม

OMRON

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
13,221.00 ฿
13,221.00 ฿
Sale Sold out

รายละเอียด Temperature Controllers OMRON E5CD-QX2A6M-002

E5CD Digital Temperature Controllers


E5CD series digital PID temperature controllers optimise control by detecting status changes and satisfy both productivity and quality in various applications.

Features and Benefits


48 x48 mm
4-digit, dual displays PV/SV
Functions specialised for packaging machines
Functions specialised for water-cooled extruders
Indication data (power ON time, ambient temperature and output On/Off count)
Draw-out structure for easy maintenance

Omron - E5GC, E5CC, E5EC, E5AC, E5DC, E5CN & E5CB Ranges

Specifications

คุณสมบัติ Value
Output Type PNP, SSR
Supply Voltage 100 → 240 V ac
Size 48 x 48mm
Number of Inputs 2
Number of Outputs 2
Minimum Operating Temperature -10°C
Maximum Operating Temperature +55°C
Temperature Range -10 → +55 °C
Control Type Temperature Control
Communication Module Available Yes
Display Type 11-Segment Digital Display
IP Rating IP00, IP20, IP66
Input Type Analogue, Temperature
Series E5CD
Range Omron E5CD
Mounting Type Panel Mount
Termination Type Screw
Panel Depth 62mm
View full details
