- Staircase timer, Electronic 16a Code. 149182300000
Staircase timer, Electronic 16a Code. 149182300000
Staircase timer, Electronic 16a Code. 149182300000
Regular price
2,749.90 ฿
Regular price
Sale price
2,749.90 ฿
Unit price
/
per
FINDER
รายละเอียด Staircase timer, Electronic 16a Code. 149182300000
Product details / Product Details
Single function stair light timer (Timed stair light) All 3 connectors are on the same side. Time range from 30 seconds to 20 minutes. Supports "zero crossing" load switching. Compatible with both mechanical and push-button electrical systems. (Low brightness) Suitable for 3 or 4 wire systems via "push button configuration"
Technical features:
- Contact configuration: 1 NO
- Size: 17.5x84x56.5 mm.
- Finder Series: Electronic Stair Timer 16 A
- Rated current: 16 A
- Rated voltage: 230 V AC
- Power supply model: AC power supply model
- Technical description: Electronic stair timer, 35 mm rail (EN 60715) mounting type, single function, 3 poles, 1 pole, 16 A, AC power supply model, rated voltage 230 V, operating From 184 to 253 V, power 3 VA (AC) / 1.2 W (DC), ambient temperature from -10 to +60 °C.
- Type: 35 mm rail (EN 60715) mounting type, single function, 3 pole.
