Stair timer function: Set the time to automatically turn off the stair lights. Adjustable from 30 seconds to 20 minutes.
Stair timer + maintenance function: keep the lights on for maintenance or cleaning.
Light on function: Turn on the stair lights directly.
Suitable for 3 or 4 wire systems. The system automatically detects the type of system.
Technical features:
Contact information: 1 NO.
Size: 17.5x84x56.5 mm.
Nominal contact current: 16 A
Nominal contact voltage: 230 V AC
Power supply model: AC power supply model
Technical description: Electronic ladder timer, 35 mm rail (EN 60715) mounted, 3 functions, 1 terminal, 16 A, AC power supply model, nominal voltage 230 V. , Operating from 184 to 253 V, rated power 3 VA (AC) / 1.2 W (DC), ambient temperature from -10 to +60 °C.
