Staircase timer Code. 140182300000

Product details / Product Details

Staircase timer Multifunctional with 16 A output contacts, "switch-off warning" option, 17.5 mm wide. Functions:

• Timed stair lights (resettable)
• Timed stair lights (resettable) + stair maintenance
• Timed stair light (resettable) with notification to turn off the light
• Stair lights timed (resettable) with notification to turn off lights + maintenance of stairs
• timed step relay
• Timed step relay with power off notification
• Step relay
Turn on the light

Technical features:

• Contact configuration: 1 NO
• Size: 17.5x84x56.5 mm.
• Rated contact current: 16 A
• Rated contact voltage: 230 V AC
• Power supply model: AC power supply model
• Technical description: Electronic stair stopwatch, 35 mm mounting rail (EN 60715), 8 functions, 1 pole, 16 A, AC power supply model, rated voltage 230 V, operating from 184 to 253 V. , Power rating 3 VA (AC) / 1.2 W (DC), Ambient temperature from -10 to +60 °C.
• Type: 35mm mounting rail (EN 60715), 8 functions
