• มีดกลึง ขนาด SCLCR 1010E06 INDEXA
1 1

Turning knife size SCLCR 1010E06 INDEXA code IND1064420K

Turning knife size SCLCR 1010E06 INDEXA code IND1064420K

2,594.00 ฿
2,464.00 ฿ 2,594.00 ฿
Sale Sold out

INDEXA

รายละเอียด Turning knife size SCLCR 1010E06 INDEXA code IND1064420K

  • Approach Angle: 95 °
  • Clearance Angle: 7 °
  • Coolant Delivery: External
  • Cutting Direction: Left Hand
  • Cutting Height (h1): 10 mm.
  • Head Length (l2): 10 mm
  • ISO Designation: SCLCL 1010E06
  • Insert Cutting Edge Length: 6 mm
  • Insert Holding Type: Screw -On
  • Insert Inscribed Circle: 6.35 mm
  • Insert Shape: 80 Rhombic
  • Insert Size: 602
  • Insert Style: CC_T
  • Inserts Included: None
  • MFR Part No.: SCLCR1010E06
  • Neck Length: 10 mm
  • Overall Length (l1): 70 mm
  • Set Type: Individual Toolholder
  • Shank Height (h): 10 mm.
  • Shank Material: Steel
  • Shank Style: Offset
  • Shank Width (b): 10 mm.
  • Side to Cutting Tip (f): 12 mm.
  • Toolholder Style: SCLC
