Safety Relay Pilz PNOZ m ES Profibus Code 772132

Technical Data Sheets :

PNOZmulti 2 Communication/Fieldbus Module Profibus

• The PNOZ m ES Profibus expansion module connects to a base unit from the PNOZmulti 2 configurable control system.

Features and Benefits

• Can be configured in the PNOZmulti Configurator
• Connection for PROFIBUSDP
• Station addresses from 0 ... 99, selected via rotary switch
• Status indicators for communication with PROFIBUSDP and for errors
• In the PNOZmulti Configurator, 128 virtual outputs of the PNOZmulti 2 control system can be defined for communication with the fieldbus PROFIBUSDP
• Maximum 1 PNOZ m ES Profibus can be connected to the base unit
• Transmission rate: maximum 12 Mbps
• Connection to fieldbus via female 9-pin D-Sub connector

Approvals

• CE, cULus Listed, TÜV, BG, CCC.
• Supplied with
• Screw terminals.
