Murrelektronik Circular Connector Code 7000-78201-0000000

The Murrelektronik Limited 7000 series 5-contact M12 female cable connector has a socket in-line connection. This field-wireable screw-type connector has a voltage rating of 60VAC/DC and a current rating of up to 4A per contact. This connector features plug-in mating with a threaded locking mechanism for an easy and secure connection. This plastic housed cable connector has good resistance to oils and chemicals. It features a screw terminal that allows the field construction and repair, with a cable clamp section of 6mm and 8mm in diameter.
Murrelektronik sensor-Actuator cable assemblies and connectors
A comprehensive offering of M8 and M12 connector cable assemblies, distribution units, M8 and M12 connectors, Fieldbus connector cable assemblies, couplers and tooling from Murrelektronik.

Straight body orientation
Screw termination
Easy mating and unmating
Maximum connection cross section is 1.5mm²
Operating temperature ranging between -25°C and 85°C
Shielded

Machine tools
Manufacturing
Metal cutting
Production lines

EN60529
IP67 rated
