Murrelektronik Circular Connector Code 7000-14621-0000000

Murrelektronik Circular Connector Code 7000-14621-0000000

รูปสินค้าอาจไม่ตรงกับของจริง รบกวนสอบถามแอดมินเพื่อขอดูรูปเพิ่มเติม

Murrelektronik

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
2,300.00 ฿
2,706.00 ฿ 2,300.00 ฿
Sale Sold out

รายละเอียด Murrelektronik Circular Connector Code 7000-14621-0000000

MOSA M12 Field-Wireable IDC Cable Connectors, B and D Coded, Shielded


MOSA series M12 field-wireable cable mount connectors from Murr Elektronik, offered in male and female 2 way B coded or 4 way CAT5, D coded variants.These M12 connectors feature IDC terminals allowing in the field construction and repair are fully shielded and are IP67 rated once mated.

Operating voltage 32 Vac/dc (B coded), 50 Vac/dc (D coded)
Operating current 4A Max.
IP67 once mated
Operating temperature range -40 to + 85 °C
Connections cross section 0.25-0.34mm2

Standards

EN60529


MURR Elekronik Sensor - Actuator Cable Assemblies and Connectors


A comprehensive offering of M8 and M12 connector cable assemblies, distribution units, M8 and M12 connectors, fieldbus connector cable assemblies, couplers and tooling from MURR Elektronik.
คุณสมบัติ
Value
Number of Contacts 4
Mounting Type Cable Mount
Connector Size M12
Plug/Socket Socket
Contact Gender Female
Termination Method IDC
IP Rating IP65, IP67
Current Rating 4.0A
Series 7000
Body Orientation Straight
Coding D
Voltage Rating 50.0 V
Mating Type Plug-In
Minimum Operating Temperature -40°C
Maximum Operating Temperature +85°C
