Murrelektronik Circular Connector Code 7000-14521-0000000

The Murrelektronik Limited 7000 series 4-contact M12 male bulkhead cable connector has a plug in-line connection. This cable mount field -wireable(IDC) connector has a voltage rating of 32VAC/DC and a current rating of up to 4A per contact. This connector has a plug-in mating with a threaded locking mechanism for an easy and secure connection. Its housing is constructed from impact-resistant plastic with D coding and Ethernet CAT5. This connector features IDC termination and has good resistance against chemicals, oils, lubricants, coolants and other aggressive media.
Murrelektronik sensor-Actuator cable assemblies and connectors
A comprehensive offering of M8 and M12 connector cable assemblies, distribution units, M8 and M12 connectors, Fieldbus connector cable assemblies, couplers and tooling from Murrelektronik.

Straight body orientation
Screw termination
Connection cross section ranging between 0.14mm² and 0.34mm²
Easy mating and unmating
Operating temperature ranging between -40°C and 80°C
Outer cable diameter ranging between 4.5mm and 8.8mm
Shielded

Machine tools
Manufacturing
Metal cutting
Production lines

EN60529
IP67 rated
