| Gross weight |
0.412 Kg |
| Net weight |
0.356 Kg |
| Volume |
0.617 Liter |
| EAN |
5702428155731 |
| Acid capacity [g] |
0.54 g |
| Acid capacity [oz] |
0.019 oz |
| Activated alum/Molec sieve [%] |
0% / 100% |
| Approval |
UL |
| Body material |
Steel |
| Braket |
No |
| Brand |
ELIMINATOR |
| Connection material |
Steel |
| Core |
Solid core |
| Core Size code |
08 cu.in. |
| Drying Cap[Drops of Water]24°C |
R134a: 250 |
| Drying Cap[Drops of Water]52°C |
R134a: 229 |
| Flow capacity [kW] |
R134a: 16.0 |
| Flow capacity [TR] |
R134a: 4.5 |
| Flow direction indicator |
Label printed 1-way arrow |
| Fluid Group |
2 |
| In scope of WEEE and contain batteries |
No |
| Inlet 1 connection size [in] |
3/8 in |
| Inlet connection size [mm] |
10 mm |
| Inlet connection type |
Flare |
| LiqCap Cond (ARI 710-2009)[SI] |
Delta p=0.07bar tliq= 30°C tvap=-15°C |
| LiqCapCond (ARI 710-2009)[IMP] |
Delta p=1psi tliq= 86°F tvap=5°F |
| Lubricants compatibility |
Oilfree applications |
| Max. Working Pressure [bar] |
46 bar |
| Max. Working Pressure [psig] |
667 psig |
| Net volume [foz US] |
3.87 Fluid Ounce US |
