Carlo Gavazzi Capacitive Block-Style Proximity Sensor Code EC5525PPAP-1
Carlo Gavazzi Capacitive Block-Style Proximity Sensor Code EC5525PPAP-1
CARLO GAVAZZI
āļāļĢāļļāļāļēāļāļĢāļ§āļāļŠāļāļāļŠāļāđāļāļāļāđāļāļāļāļģāļĢāļ°āđāļāļīāļRegular price
8,398.00 āļŋ
Regular price
10,498.00 āļŋ
Sale price
8,398.00 āļŋ
Unit price
/
per
Couldn't load pickup availability
āļĢāļēāļĒāļĨāļ°āđāļāļĩāļĒāļ Carlo Gavazzi Capacitive Block-Style Proximity Sensor Code EC5525PPAP-1
Carlo Gavazzi Capacitive Proximity Sensor
Capacitive proximity sensors from Carlo Gavazzi provide the user with a durable sensing solution. Come supplied in both flush & non-flush options to ensure your application is covered
M18 polyester housing with either a free lead or an M12 plug
TRIPLESHIELD sensor protection options available
Flush & Non-flush mounting options available
LED status indication
Plug & cable versions available
TRIPLESHIELD sensor protection options available
Flush & Non-flush mounting options available
LED status indication
Plug & cable versions available
āļāļļāļāļŠāļĄāļāļąāļāļī |
Value |
|---|---|
| Sensor Technology | Capacitive |
| Body Style | Block |
| Output Type | PNP |
| Detection Range | 25 mm |
| Terminal Type | 4-Pin M12 Connector |
| Supply Voltage | 10 â 40 V dc |
| IP Rating | IP67 |
| Length | 35mm |
| Width | 68.3mm |
| Switching Frequency | 100 Hz |
| Depth | 15mm |
| Maximum DC Voltage | 40V |
| Switching Current | 200 mA |
| Shielding | Partial |
| Housing Material | PC |
| Maximum Operating Temperature | +70°C |
| Reverse Polarity Protection | Yes |
| Short Circuit Overload Protection | Yes |
| Minimum Operating Temperature | -25°C |
Datasheet - EC5525PPAP-1
