• Carlo Gavazzi Capacitance Switch Level Sensor Code VC5510PNOP
1 1

Carlo Gavazzi Capacitance Switch Level Sensor Code VC5510PNOP

Carlo Gavazzi Capacitance Switch Level Sensor Code VC5510PNOP

รูปสินค้าอาจไม่ตรงกับของจริง รบกวนสอบถามแอดมินเพื่อขอดูรูปเพิ่มเติม

CARLO GAVAZZI

กรุณาตรวจสอบสต็อกก่อนชำระเงิน
4,286.00 ฿
5,357.00 ฿ 4,286.00 ฿
Sale Sold out

รายละเอียด Carlo Gavazzi Capacitance Switch Level Sensor Code VC5510PNOP

Carlo Gavazzi Level Sensor


The Carlo Gavazzi capacitive level sensor has to sense range from 2mm to 10mm and it can be adjustable via a single turn potentiometer. It comes in a flat-pack housing, It is easy mounting with two M4 screws. It is 35mm wide and 55mm long. Its supply voltage ranges between 5VDC and 30VDC.

Features and Benefits


LED indication when activated
Output is DC 100mA, PNP type
Power ON delay

Max 40ms (No delay version), Max 5s (ON/OFF delay versions)
No-load supply current is less than 10mA
Housing material is grey, ABS and polycarbonate

Applications


Whirlpools for switching ON/OFF the heating element
Starting and stopping the air pumps
Controlling the level of the water, disinfection fluid, etc.

Certifications


UL approved
CE certified
IP65 rated

คุณสมบัติ
Value
Device Type Capacitance Switch
Mounting Type Chassis Mount
Switch Output PNP
Body Material ABS/Polycarbonate
Cable Length 1.5m
Minimum Operating Temperature 0°C
Maximum Operating Temperature +50°C
Maximum DC Voltage 30V
Maximum Current 100 mA

Datasheet - VC5510PNOP
View full details
