Burkert Solenoid Valve 3/2 Way Direct Acting Type 6012 Code 425290

Name: Burkert Solenoid Valve 3/2 Way Direct Acting Type 6012 Code 425290
Brand: Burkert
Price: 3018.31 THB
Availability: InStock

Burkert

3,018.31 ฿

Sale Sold out

Quantity

รายละเอียด Burkert Solenoid Valve 3/2 Way Direct Acting Type 6012 Code 425290

Data Sheets :

Code	425290
Supply Voltage	230 V ac
Number of Ports	3
Connection Size	1/4in
Connection	1/4 in G Female
Operation	Direct
Default Valve Position	NC
Suitable Applications	Liquid, Neutral Gas
Type	44960
Orifice Diameter	1.2mm
Body Material	Polyamide
Maximum Working Pressure	10 bar
Operating Temperature Range	-10 → +55 °C
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+55°C
Connection Gender	Female
Thread Standard or Connection Type	G
Series	6012
Maximum Closing Time	12ms
Flow Factor Kv	0.045m³/h
Maximum Opening Time	10ms
